MBJ3rFM+3UU 700

Code 223612

3 Inputs

3 input (FM+III+DAB, UHF) multiband TV indoor amplifier with 32dB gain and output level up to 120dBμV in UHF band, separate amplification, independent level adjustment (20dB) for each input and low noise figure. Built-in 694MHz 5G and 4G LTE filter.

Technical chars

A.B.L.A. functionality: exclusive FRACARRO system for constant maintenance of the output level set even when the level of each input changes (independent A.B.L.A. circuits) with output level stabilization even for high variations in the input TV signal and LED operation of dedicated A.B.L.A. circuits.
High shielding against LTE interference (LTE Free)
Protective shell: the new switchboards are equipped with a flame-retardant and non-propagating (Class V0) ABS material enclosure
Prepared for mounting on standard DIN rail with quick release.
The overall dimensions of the MBJ EVO T2s are designed so that they can be easily installed inside wall boxes.
Very high efficiency switching power supply (>80%) and self-resetting short-circuit protection circuit.
Selector switch for inserting remote power supply on each UHF input (100mA total).
Power supply status LED.
Faston for connection to TV system grounding.

Specifications
		MBJ3rFM+3UU 700
Code		223612
Input no.		3
Inputs		FM+III+DAB, UHF, UHF
Frequency FM	MHz	88 - 108
DAB, III Frequency	MHz	174 - 230
Frequency	MHz	470 - 694
Gain	dB	FM+III+DAB: 32; UHF: 32; UHF: 32
Gain adjustment	dB	FM+III+DAB: 20; UHF: 20; UHF: 20
Optical noise figure	dB	FM+III+DAB: 6; UHF: 9
Outputs number		1
Output level	dBµV	III+DAB: 110; UHF: 120
Connectors		F female
Filter		5G
Power supply voltage	Vdc/A	220-230 / 50-60
Current consumption	W	6
Remote feeding		100mA@12V total
Operating temperature	°C	-10 to +55
Protection		IP20
Conformity		EN62368-1:2014/AC:2015; EN50083-2:2012/A1:2015
Dimensions and packaging
Pieces		1
EAN code		8016978103577
Packaging dimensions	mm	152 x 107 x 153
Product dimensions	mm	101 x 150 x 40
Packaging weight	kg	0.286
Net Weight	kg	0.325
Weight	kg	0.325
