CD4-14
Code 220854
CAD-S Series
4-output clamp tap with 14dB attenuation of the CAD-S series in TV and Satellite band (5-2400MHz).
Technical chars
- Perfect Class A shielding and optimal impedance matching.
- CAD-S series taps are the only wideband taps with a dedicated clamp on each cable to use different diameter cables on adjacent ports.
- Fracarro's patented features make them reliable and easy to install.
| CD4-14 | ||
| Code | 220854 | |
| Taps | 4 | |
| Insertion loss | ||
|---|---|---|
| RC 5-40MHz | dB | 3.5 |
| TV 47-862MHz | dB | 3.3 |
| SAT 950-1750MHz | dB | 3.7 |
| SAT 1750-2150MHz | dB | 4.5 |
| SAT 2150-2400MHz | dB | 5 |
| Tap loss | ||
| RC 5-40MHz | dB | 14 |
| TV 47-862MHz | dB | 14 |
| SAT 950-1750MHz | dB | 14.5 |
| SAT 1750-2150MHz | dB | 14.5 |
| SAT 2150-2400MHz | dB | 14.5 |
| Outputs Isolation | ||
| RC 5-40MHz | dB | 30 |
| TV 47-862MHz | dB | 30 |
| SAT 950-1750MHz | dB | 30 |
| SAT 1750-2150MHz | dB | 25 |
| SAT 2150-2400MHz | dB | 25 |
| Specifications | ||
| Tap loss | dB | 14 |
| Dimensions and packaging | ||
| Pieces | 8 | |
| EAN code | 8016978075140 | |
| Multiple EAN | 8016978075560 | |
| Packaging dimensions | mm | 155 x 90 x 65 |
| Packaging weight | Kg | 1.161 |
